Cable tray straight-through accessories are components used to join, support, and extend straight sections of cable trays, ensuring structural integrity and proper cable routing. OverviewStraight-through accessories are essential for connecting two sections of cable tray in a linear configuration. They maintain alignment, provide mechanical support, and allow for continuous cable pathways without sagging or misalignment.

These accessories are compatible with various tray types, including wire mesh, ladder, and solid-bottom trays.

Common Types of Straight-

Through Accessories

Straight Connectors / Butt-Splice Kits: Used to join two straight tray sections end-to-end. They typically include bolts, washers, and nuts, and may be zinc-plated or steel for corrosion resistance. Clamp Connectors: Secure trays together after bending or cutting, ensuring a stable connection while allowing minor adjustments.

Center Supports / Hangers: Provide additional support for long tray runs, preventing sagging and maintaining load capacity. These are often mounted to walls, ceilings, or threaded rods. Splice Kits: Pre-packaged kits that include all necessary hardware to join straight sections, often UL or cULus classified for safety compliance.

Dropouts / End Supports: Facilitate smooth cable exit from the tray while reducing stress on cables at the ends of straight sections.

Installation Considerations

Ensure the accessory matches the tray type and width to maintain structural integrity. Use appropriate fasteners (bolts, nuts, washers) as specified by the manufacturer; some kits may require separate purchase of hardware. For long runs, center supports should be installed at recommended intervals to prevent sagging and maintain load capacity, which can be up to 280 lbs per foot depending on tray type and support spacing.

Verify corrosion resistance for the environment; zinc-plated or stainless steel accessories are common for industrial or outdoor applications.

Summary

Cable tray straight-through accessories are critical for creating continuous, stable, and safe cable pathways. By using connectors, splice kits, clamps, and supports, installers can maintain alignment, prevent sagging, and ensure proper cable management across long runs. Selecting the correct accessory type and material ensures compatibility with the tray system and compliance with safety standards.
