Installation Technology of Tubular Busbars

Tubular busbars are installed by careful handling, secure mounting on support brackets, proper alignment, and safe electrical connections, following strict safety and standard compliance procedures.

Material Selection and Preparation

Tubular busbars are typically made of copper or aluminum, chosen based on current-carrying capacity, thermal stability, and mechanical strength. Before installation, inspect each busbar for transport damage, remove protective wraps only when ready to mount, and ensure plastic end caps remain in place to protect conductors until final connection. The cross-sectional area must match the expected load to prevent overheating, and vertical placement is preferred for better heat dissipation.

Handling and Lifting

Due to their weight and rigidity, tubular busbars require mechanical lifting aids such as Geni lifts, scissor lifts, or platform lifts for safe handling. Always lift by the main body, not the ends, and ensure slings and hooks are rated for the busbar load. Conduct a risk assessment before lifting, and follow manual lifting guidelines for sections under 25 kg.

Personal protective equipment (PPE) is mandatory during all handling and installation steps.

Mounting and Support

Install support brackets or suspension systems first, ensuring they are sturdy, level, and compliant with standards. Tubular busbars are then mounted onto these supports, maintaining proper spacing to prevent electrical arcing and allow airflow for cooling. Insulators or bushings are used to electrically isolate the busbar from the panel or enclosure while providing mechanical stability.

Protective nets or covers may be installed to prevent accidental contact.

Alignment and Connection

Align busbar sections carefully to ensure tight, clean joints. Loose connections increase resistance, leading to heat buildup and potential fire hazards. Bolted connections are common, and torque specifications must be followed.

For multi-phase systems, maintain consistent spacing and orientation to reduce electromagnetic interference and ensure balanced load distribution.

Safety and Compliance

Before energizing, verify that the panel is completely de-energized and use insulated tools for all electrical work. Follow lockout/tagout procedures, and conduct inspections of supports, insulators, and protective covers. Installation should comply with relevant standards such as IEC 61439 for low-voltage switchgear, ensuring both safety and performance.

Final Checks

After installation, perform a visual and mechanical inspection of all busbar sections, supports, and connections. Confirm proper grounding, absence of protrusions, and secure mounting. Only after these checks should the system be energized.

By following these steps, tubular busbars can be installed safely, efficiently, and in compliance with industry standards, ensuring reliable power distribution and long-term operational stability.
