Cable Tray Accessories Cable Model and Specification Table

Cable tray accessories include elbows, tees, reducers, covers, joint connectors, and mounting hardware, with specifications varying by manufacturer, material, and load rating.

Common Cable Tray Accessories and Specifications

Accessory TypeDescriptionMaterial / FinishTypical Sizes / ModelsNotesElbow (Horizontal / Vertical)Changes cable direction horizontally or verticallySteel (hot-dip galvanized, pre-galvanized), Aluminum50–600 mm width, 50–200 mm heightAvailable in inside/outside configurations; radius varies by manufacturer Tee / CrossSplits or joins cable runsSteel, AluminumWidths matching straight sectionsUsed for branching cable trays; may include covers ReducerConnects trays of different widthsSteel, AluminumStandard widths (e.g., 100–600 mm)Ensures smooth cable transition between tray sizes Cover / LidProtects cables from dust, debris, or mechanical damageSteel, Aluminum, PVCFull-length or sectionalCan be ventilated or solid; clips or screws for attachment Joint Connector / Splice PlateConnects two straight tray sectionsSteel, AluminumWidths matching trayProvides mechanical continuity and grounding; may include bolts Mounting Brackets / SupportsSecures trays to walls, ceilings, or racksSteel, AluminumAdjustable lengths and anglesIncludes J-bolt kits, strut channels, or clamps; load rating depends on span Cable Tray Hanger / Suspension KitSuspends trays from ceilingsSteel, AluminumAdjustable rods, clampsSupports long runs; ensures proper bend radius and strain relief Cover Clip / FastenerSecures covers to traysSteel, PlasticStandardized per tray widthEnsures cover stability and safety Manufacturer-Specific NotesLegrand provides a detailed technical guide with accessory specifications, including mechanical and electrical characteristics, CE marking compliance, and installation recommendations.

Eaton B-

Line series offers a submittal builder tool to filter and download accessory models, CAD/BIM files, and specifications for straight sections, fittings, and accessories.

AB

B / T&B Cabletray catalogs include ASTM A123 & ISO 1461 compliance, UL certifications, and CAD/BIM drawings for fittings, covers, and accessories. King Power Technology lists accessories with dimensions, surface treatments (hot-dip galvanized, powder-coated), and compatibility with straight tray sections. Hubbell NEXTFRAME® Ladder Tray provides modular accessories for data centers, including J-bolt kits, mounting brackets, and load-class specifications.

Key Considerations

Material and Finish: Choose based on indoor/outdoor use, corrosion resistance, and electrical grounding requirements. Load Rating: Accessories must match the tray's load class and support span. Compatibility: Ensure accessory dimensions match the tray width, height, and type (ladder, ventilated, solid-bottom).

Installation: Some accessories require specific fasteners or mounting hardware; check manufacturer guidelines. Standards Compliance: Verify CE, UL, NEMA, or ASTM certifications for safety and regulatory compliance. This table and notes provide a comprehensive overview of cable tray accessories, their models, specifications, and installation considerations for industrial, commercial, and data center applications.
