Are dual-fiber optical modules divided into A and B How are they differentiated

Fiber and communications infrastructure knowledge brief Published 02 Aug 2025

Use this reference to prepare product questions for BAGYOU FIBRE. Check interfaces, capacity, protection and installation requirements against the current product documentation.

Dual-fiber optical modules are not inherently divided into A and B; they are differentiated by TX (transmit) and RX (receive) ports, with each fiber dedicated to one direction of data flow. Structure and FunctionDual-fiber optical modules use two separate fibers: one for transmitting (TX) and one for receiving (RX) optical signals. Unlike single-fiber (BiDi) modules, which require A/B pairing to handle bidirectional communication on a single strand using different wavelengths, dual-fiber modules operate with one fiber per direction, so there is no intrinsic A/B designation.

T

X Port: Sends optical signals from the module to the remote device.

R

X Port: Receives optical signals from the remote device. The fibers are typically connected using a duplex patch cord, which ensures that the TX of one module connects to the RX of the other, and vice versa. DifferentiationDual-fiber modules are differentiated by: Port Labeling: The module will have clearly marked TX and RX ports.

Correct pairing is essential for proper communication. Wavelength: Dual-fiber modules generally use the same wavelength for both directions (e.g., 850 nm, 1310 nm, or 1550 nm), unlike single-fiber BiDi modules, which use different wavelengths at each end and require A/B matching. Fiber Count: Dual-fiber modules require two fibers, whereas single-fiber modules use only one.

Practical Implications

When installing dual-fiber modules, ensure that TX connects to RX on the opposite end. There is no need for A/B labeling as in BiDi single-fiber modules; the distinction is purely based on the TX/RX ports. Using the correct duplex patch cord and matching the module's wavelength and speed ensures reliable communication.

In summary, dual-fiber optical modules are differentiated by TX and RX ports and fiber count, not by A and B ends.

A/

B pairing is specific to single-fiber BiDi modules that transmit bidirectionally over a single fiber using different wavelengths.
